OPB990T55Z spot TT/Optek original factory agent photoelectric sensor slot photoelectric switch
Category:
electron/Photoelectric sensor/Optics Optical Interrupter Slot Transistor Output
Model:
OPB990T55Z
Brand:
TT Electronics / Optek
Retail Price
10,000,000.00USD
重量
kg
- Product Description
-
Description :
TT Electronics/Optek Agent Shenzhen Huitong Innovation Technology Co., Ltd
Mr. Ping: 15323706628
Description:
OPB990T55Z is a sensor with a slotted optical switch that uses near-infrared (850-940nm) LED emitter and detector to detect the presence or movement of objects. This sensor features a 0.125 "(3.18mm) wide slot where users can specify the output logic state, output driver circuit, aperture width, aperture surface, and installation label position. In addition, wires or PCB leads can be selected to provide flexibility in electrical interfaces. The device body is made of opaque plastic to minimize sensitivity to visible and near-infrared external light sources that may affect operation.
characteristic:
- Optional logic and output driver circuits
- Optional aperture size with options for coverage or openness
- Wire or PCB lead
- Optional installation features
- Direct TTL, LSTTL, CMOS interfaces
- Compliant with the EU RoHS Directive 2002/95/EC
- Optional aperture width guide options: 55, 51, 11 (see aperture width guide for details)
- Installation label position: L - transmitter, N - none, P - sensor, T - both (two installation labels)
Application:
- Speed and direction indication (e.g. rotary encoder)
- Mechanical switch replacement
- Mechanical limit indication
- Printer - Top, End of Journey, Start Position
- Sliding doors, automotive and lift door applications
Technical specifications:
- Storage temperature range: -40 ° C to+85 ° C
- Working temperature range: -40 ° C to+70 ° C
- Input diode power dissipation: 100 mW
- Output Photologic ® Power dissipation: 200 mW
- Supply voltage (VCC to ground): 18V
- Output current to ground (IOS): maximum 30 mA per second
- Output rise time and fall time: 70 ns (at 5.0V VCC, IF peak=15 mA, TA=25 ° C)
- Output logic state comparison (left to right blocking distance) and (top to bottom blocking distance)
OPB880T51Z, OPB818, OPB830W51Z, OPB880P51Z, OPB990T55Z, OPB840W55Z, OPB890T11Z, OPB815WZ, OPB620, OPB9000, OPB830W55Z, OPB993L11Z, OPB315WZ, OPB857Z, OPB992P51Z, OPB610, OPB940W51Z, OPB933W51Z, OPB829DZ
OPB350L125, OPB350L187, OPB350L250, OPB350W062Z, OPB350W125Z, OPB350W250Z
OPB13042, OPB743WZ, OPB732WZ, OPB733TR, OPB9000
OPB100-SZ, OPB100-EZ, OP133, OP805SL, OP266A, OP506A, OP224, OP644SL
