Laboratory full temperature shaker, constant temperature oscillation incubator, used for biomedical research and development
Category:
chemical industry/Life Science Instruments/Shaker, oscillator
Model:
BYQZ-1210B
Brand:
Xieyang
temperature range:
4~60℃
temperature control accuracy:
±0.1℃
oscillation frequency:
0~300rpm
Oscillation amplitude:
20mm
timing range:
0-999 hours
inner material:
Stainless Steel
temperature control :
Microcomputer PID
Applicable fields:
Biology/Medicine/Teaching and Research
Retail Price
10,000,000.00USD
重量
kg
- Product Description
-
temperature range 4~60℃
temperature control accuracy ±0.1℃
oscillation frequency 0~300rpm
Oscillation amplitude 20mm
timing range 0-999 hours
inner material Stainless Steel
temperature control Microcomputer PID
Applicable fields Biology/Medicine/Teaching and Research
Description :
The full temperature shaker is a precision biochemical instrument that integrates heating, cooling, and oscillation functions. It aims to solve the pain points of traditional incubators being unable to mix liquids and ordinary oscillators being unable to accurately control temperature. It achieves precise constant temperature control over a wide temperature range through the collaborative work of compressor refrigeration and electric heating system, while providing a stable and uniform oscillation environment. The typical operating conditions of this equipment are suitable for scenarios that require specific temperature conditions for cell culture, fermentation research, hybridization reactions, and enzymatic experiments. It is an indispensable basic equipment in biology, medicine, health and epidemic prevention, and university teaching and research laboratories. It can effectively simulate the temperature changing environment in nature, ensuring the repeatability and accuracy of experimental data.
The full temperature shaker has heating and oscillation functions, and is a biochemical instrument that effectively combines a constant temperature box and an oscillator. It is widely used in the fields of biology, medicine, health, teaching and research, and is one of the commonly used instruments in laboratories.
2、 Characteristics:
1 Microcomputer temperature control, speed regulation, and time integration, easy to operate, clear and intuitive.
2 Forced air convection design ensures uniform temperature inside the box.
3 The large viewing angle observation window allows for a clear understanding of the working conditions inside the box.
4 Mirror stainless steel inner liner, easy to clean.
5 Brushless DC motors are suitable for continuous operation.
6 Has high brightness lighting function.
7 UV sterilization function.
8 30 segment program control, with historical temperature, speed, and time storage function, and external USB flash drive function (subject to request)
3、 Technical parameters:
1 Temperature control range: 4-60 ℃
2 Temperature control accuracy: ± 1 ℃
3 Temperature fluctuation: ± 0.5 ℃
4 Temperature control method: microcomputer PID control
5 Heating power: 600W
6 Oscillation mode: Cyclotron
7 Oscillation amplitude: Φ 26
8 Speed range: 30-300 rpm ± 1 rpm
9 Timing range: 1-9999 minutes or normally open
10 Power supply: 220V 50Hz
11 Bottling capacity: 1000ml x 12, tray size: 560 x 420
12 Dimensions: 900 × 560 × 900mm
