Description :

DDLF-1040ZZ RP0 P25 LY121 (NMB Meibeiya Flange Micro Bearing)

1、 Dimensions (mm)

• Inner diameter d:four
• Outer diameter of bearing body D:ten
• Width B:four
• Flange outer ring diameter D ₁:eleven point six, flange thickness:zero point eight
• Net weight per unit:0.001kg（1g）

2、 Load parameters

• Rated dynamic load Cr:708N
• Rated static load Cor:266N
• Extreme speed:43200r/min
• Steel ball: Φ 1.5875mm, a total of 8 pieces

3、 Model segmentation definition (NMB factory suffix)

1. DDLF：Unilateral outer ring with flange, metric micro deep groove ball(F=Flange flange)
2. one thousand and forty: Outer diameter 10mm, inner diameter 4mm
3. ZZDouble sided iron dust cover closed type
4. R：Wave shaped steel plate stamping cage
5. P0Precision grade JIS 0 (ordinary precision grade)
6. P25: Clearance group, radial clearance 5-12.5 μ m (C3 has a larger clearance)
7. LY121：NMB special high-temperature grease code(Original factory pre installed grease)

4、 Material

Ring+steel ball:440 stainless steel (9Cr18) rust preventionCold rolled steel plate for retaining frame

5、 Swap models

National standard name:SMF104ZZ (flange bearing F604ZZ)The size is completely universal

6、 Application

Precision motors, micro gearboxes, automated small shafts, medical equipment, gimbal motors, precision instruments.
