scroll plate

Description :

Static vortex diskandorbiting scroll Two sets are paired for use, forming a disc-shaped structure with an integrated involute spiral vortex tooth on the disc surface. By relying on the meshing of the yin-yang vortex teeth, a continuous closed compression chamber is formed

After tempering, hardening, and surface wear-resistant spraying treatment, it has high strength, high temperature resistance, and deformation resistance. During work, the moving disk performs circular translation without rotation, gradually reducing the volume between teeth and completing the entire process of gas suction, compression, and exhaust.

Compact structure, smooth transmission, low vibration, low noise, high compression efficiency, long wear resistance and service life. Paired with vortex seals, it can significantly reduce internal gas leakage and is widely used in central air conditioning, heat pump units, new energy heat pumps, air compressors, refrigeration equipment and other fields. It is a key core component that determines the energy efficiency, stability and service life of compressors.
