DGM 8x42 8MP telescope
Category:
Instrumentation/optical instrument/telescope
Model:
DGM 8x42 8MP
Brand:
Kenat
Retail Price
10,000,000.00USD
重量
kg
- Product Description
-
Description :
model Specification parameter table DGM 8x42 8MP Optical structure optical parameters model 8x42 magnification 8x Eyepiece aperture 26mm Objective aperture 42mm Angular field of view 7.5° Line of view field 131m/1000m 393ft/1000yd optical parameters
-ConfigurationDiopter Control ±4 Exit pupil distance 17mm Optical structure Exit pupil diameter 5.36mm close range 4m Eyepiece configuration 3 groups of 4 pieces Objective lens configuration 3 groups of 4 pieces Prism BAK4 coating FMC eye mask Rotating eye mask waterproof Nitrogen filled waterproofing motherboard Photo Specifications Camera resolution 3840x2160 (Link phone camera pixel 1920X1080) motherboard Photo Specifications Shoot in the middle Support the function of taking photos in the camera
(Does not affect the camera)
Resolution of 2 millionimage format JPEG Video specifications video resolution 1920X1080 Image compression format MP4（ H264/H265） , default H.265 Storage Memory Maximum support for 128GB TF card storage Functional UI LED status indicator light Red light (charging constantly on, fully charged off, photo/video red light flashing);
Green light (always on when turned on, always on when fully charged, flashing when connected to WIFI)
Traffic light exchange flashing (recording while turning on WIFI)LED power indicator light Constant green light - green light for battery level greater than or equal to 50%;
Constant yellow light - battery level greater than or equal to 20% and less than 50%;
Constant red light - battery level less than 20%;
Flashing red light - battery level less than 5%;
--This battery level display is only displayed when the device is turned on.button Power button (long press to turn on/off);
Recording button (short press start, end recording)
Photo button (short press to take photo, short press to take in camera);
WIFI button (long press to turn on, turn off WIFI)watermark /Year/Month/Day/Hour/Minute/Second Prompt piezoelectric buzzer Language settings 30 languages including Chinese and English are available for selection power supply battery Built in battery connector; Battery capacity 4000mA Charging Type-C port
Supports 5V/2A chargingpower supply Full power working hours
(Continuous use)10H
(WI-FI and video simultaneously open)WIFI WIFI Supports 2.4GHz AP mode,
Connect to the OneShot app for taking photos, recording videos, and more; Replay, And the parameter setting function related to the camera telescope,
Supports 3 mobile phones (Android or Apple); Preview device imageMicrophone Microphone Microphone Resident MIC Reliability Operating temperature -10℃ ~50℃ Storage temperature -20℃ ~55℃ Remarks Overseas markets: This product has been underwritten in Europe and can be sold in other overseas markets AfterSalesService :
