Tai'an Yucheng YHY60&# 40; A) Mining intrinsically safe digital pressure gauge

Description :

　　Tai'an YuchengYHY60(A)Mining intrinsically safe digital pressure gauge

　　YHY60(A)The intrinsically safe digital pressure gauge for mining has a long service life. It is supplied by Shandong Yucheng and Yucheng, a manufacturer of intrinsically safe digital pressure gauges for mining

　　1、 Introduction: YHY60 (A) intrinsically safe digital pressure gauge for mining is not unfamiliar to everyone. Some people may misunderstand this product as a single pillar side pressure gauge. In fact, YHY60A intrinsically safe digital pressure gauge for mining is also called a digital pressure gauge for mining comprehensive mining hydraulic support. Don't confuse it. Tai'an Yucheng Mining Equipment Co., Ltd. produces roof separation instruments, which can be made in various styles or customized. Mining intrinsically safe roof displacement monitoring instrument. Mining intrinsically safe digital pressure gauge. Comprehensive mining support pressure gauge, roof dynamic instrument, digital roof dynamic instrument. Digital anchor cable dynamometer. Single pillar pressure gauge, digital display single pillar pressure gauge. Anchor rod tension meter, anchor cable tensioning equipment. Mining ultrasonic rock crack detector. Hydraulic pillow. Multi point displacement sensor. There are many types. Below, I will briefly introduce the YHY60 (A) intrinsically safe digital pressure gauge for mining. This YHY60 (A) intrinsically safe digital pressure gauge (digital pressure gauge for mining fully mechanized hydraulic support) is an intelligent instrument used for monitoring pressure parameters of mining fully mechanized support underground. It has the characteristics of small size, easy operation, intuitive display, and high accuracy. It adopts an improved battery power supply system, greatly improving the reliability of instrument use and the service life of power supply. It can be used underground for a long time without maintenance.

　　2、 Technical parameters of YHY60 (A) intrinsically safe digital pressure gauge for mining:

　　1. Working current:<=25mA

　　2. Pressure gauge rating: Level 1.5

　　3. Range: 0-60MPa.

　　4. What is the diameter of the pressure hole? 10.

　　5. Display mode: LED digital display.

　　6. Communication method: infrared wireless communication, data collection and storage.

　　3、 The main technical features of YHY60 (A) intrinsically safe digital pressure gauge for mining (hydraulic support pressure gauge for comprehensive mining) are:

　　1. Adopting an integrated design of resistive pressure sensor, electronic circuit, and battery, it can be used underground for a long time.

　　2. Digital display, one click operation, simple and convenient operation.

　　3. Equipped with light controlled display function

　　4. Battery powered, low-power design, can operate continuously underground for 3 years, maintenance free fully mechanized mining support pressure gauge.

　　YHY60 (A) intrinsically safe digital pressure gauge for mining (digital pressure gauge for mining comprehensive mining hydraulic support) accuracy: 1.6% power supply: 4.5V (built-in 2 # dry battery pack) weight: 1.6 kg.

　　4、 How to install YHY60 (A) intrinsically safe digital pressure gauge for mining (hydraulic support pressure gauge for comprehensive mining):

　　Firstly, hang or fix the pressure gauge under the bracket (choose the appropriate position according to different bracket forms), and connect the sensor to the pressure measuring hole of the column through a 10mm high-pressure oil pipe.

　　5、 How to operate:

　　We can use a mining lamp to illuminate the indicator window once or press the start button, both methods can make the display window display the pressure of the left and right channels (unit: MPa). When the left indicator light is on, it displays the pressure of the left channel, and when the right indicator light is on, it displays the pressure of the right channel. After 5 seconds, the power will be automatically turned off. This product has been sold in major coal mines; It has been widely used in Inner Mongolia, Shanxi, Guizhou, Taiyuan, Sichuan, Changzhi, Lvliang, and other places. Welcome to call Tai'an Yucheng Mining Equipment Co., Ltd. Thank you for your support.
