Xinjiang mining rock electric drill KHYD80 safety explosion-proof type

Description :

　　Xinjiang mining rock electric drillKHYD80Safe and explosion-proof type

　　KHYD80Coal mine rock drill, explosion-proof rock drill, rock drill, rock drill safety explosion-proof type, Xinjiang mining rock drill

　　 Yucheng Mining's rock electric drill models include KHYD75, KHYD80, KHYD110, KHYD140, KHYD150, etc., with a full range of models, low prices, and good quality. Safe and explosion-proof, you can use it with confidence.

　　1、 Parameters of KHYD80 rock drill for coal mine:

　　2、 Characteristics of KHYD80 rock drill for coal mine:

　　The KHYD80 mining explosion-proof electric rock drill is suitable for drilling and water exploration in mines with methane or coal dust explosion/blasting hazards, and can also be used for drilling in other mines or geotechnical engineering. The KHYD series drilling rig has strong overload capacity, which can reduce some stuck or penetrated drilling, and has a high rate of hole formation due to rock inclusion. The KHYD series drilling rig requires a drilling frame to cooperate and can drill holes in any direction, such as horizontal forward or inclined upward. In order to extend the service life of the drill bit and improve the working conditions of the operator, wet drilling with water powder discharge is adopted. During the drilling operation, only the handwheel needs to be operated, and the electric drill can advance and quickly retract on its own.

　　3、 KHYD80 Coal Mine Rock Drill Usage and Precautions

　　1. Determine the installation position of the drill frame (self-made) based on the usage scenario and drilling location

　　2. First, install the chain on the host, then install the host on the runway, connect both ends of the chain to the runway, and adjust the chain rod to obtain a certain tension for the chain. Finally, fix the runway to the drilling rig.

　　3. Before drilling, turn the handwheel to neutral position and run it without load for five minutes. When the motor insulation is good, there is no abnormal sound from the rock drill, and the main shaft rotation direction is consistent with the arrow direction on the reducer, then install the drill bit and drill rod and connect the water source.

　　4. When drilling, slowly rotate the handwheel in the direction of the arrow and gently engage the clutch. When the drill bit is fully inserted into the rock, tighten the clutch with force, but not too much force

　　The KHYD80 coal mine rock electric drill uses a chain as traction, and only requires the operation of the handwheel. The drill can automatically drill forward and quickly retreat on the runway. This drill is a type of water tool that the country emphasizes must be equipped with for water exploration, water injection, and gas exploration (release) in coal mining. It can also be used as a drilling tool for tunnel excavation, road construction, water conservancy, metallurgy, earthwork and other engineering projects.
