Concrete strength tester HQC-40 has high accuracy

Description :

　　Concrete strength testerHQC-40High degree

　　HQC-40Concrete strength tester, concrete strength tester,HQC-40Price of concrete strength tester

　　Tai'an Yucheng has always been committed to producing high-quality equipment, each of which is supervised, tested, and debugged by the company's technical personnel. The HQC-40 concrete strength tester is a highly accurate instrument used to test the strength of concrete and has been widely used in various fields.

　　1、 The function of HQC-40 concrete strength tester:

　　The HQC-40 concrete strength tester is mainly used to detect the strength of sprayed concrete in anchor spraying tunnels, and can also detect the strength grade of rocks. The rock core taken out by the concrete sampling machine is placed on the concrete strength tester to measure the hardness and determine the quality of the concrete. The HQC40 concrete strength tester is an ideal tool for testing the strength of concrete.

　　2、 Parameters of HQC-40 Concrete Strength Tester:

　　Working load 30KN

　　Rated pressure: 15MPA

　　Coaxiality of two loaded cones<0.2mm

　　Test * Large core sample with a diameter of 50MM

　　Journey: 60MM

　　Test accuracy: ± 2% -5%

　　Piston area: 19.63 C ㎡

　　Weight: 20KG

　　Dimensions 365 × 250 × 165 (MM)

　　3、 The working principle of HQC-40 concrete strength tester:

　　1. Framework: The framework consists of a base, load-bearing plate, loading cone, hydraulic jack, etc.

　　According to the accuracy requirements of the instrument: the coaxiality of the two loaded cones is less than 0.2mm, and the spherical loaded cone adopts international standards with a cone angle of 60. The curvature radius of the ball end is 5mm, the piston diameter of the hydraulic jack is 50mm, and the high pressure is 15Mpa.

　　2. Core sample holder: The core sample holder is used to place the tested core sample. The diameter of the core sample holder is consistent with the diameter of the test core sample, and this instrument uses two specifications: Φ 50mm and Φ 30mm.

　　3. Hydraulic system: The hydraulic system consists of hydraulic jacks, manual oil pumps, steel pipe oil circuits, etc.

　　The HQC-40 concrete strength tester is mainly used to detect the strength of concrete and shotcrete, and can also detect the strength grade of rocks. This instrument has the characteristics of compact and reasonable structure, novel appearance, beauty, simple operation, and rapid detection.
