Hebei Anjie Environmental Protection Sodium Hypochlorite Generator Water Plant Disinfection Equipment Fully Automatic Intelligent Dosing System
Category:
mechanical equipment/Disinfection equipment/Sodium hypochlorite generator
Model:
AJ-CL500
Brand:
Anjie, Hebei
raw material consumption:
Salt ≤ 1.4kg/kg Effective chlorine
DC power consumption:
≤ 2.5kWh/kg effective chlorine
Effective chlorine concentration:
6000-8000mg/L
cooling method:
Natural cooling/water cooling
Control method:
PLC fully automatic intelligent control
Electrode material:
Titanium based precious metal coating
working power supply:
AC 380V±10% 50Hz
ambient temperature:
5℃-40℃
relative humidity:
≤90%
Retail Price
10,000,000.00USD
重量
kg
- Product Description
-
raw material consumption Salt ≤ 1.4kg/kg Effective chlorine
DC power consumption ≤ 2.5kWh/kg effective chlorine
Effective chlorine concentration 6000-8000mg/L
cooling method Natural cooling/water cooling
Control method PLC fully automatic intelligent control
Electrode material Titanium based precious metal coating
working power supply AC 380V±10% 50Hz
ambient temperature 5℃-40℃
relative humidity ≤90%
Description :
This product is an efficient sodium hypochlorite generator developed and produced by Hebei Anjie Environmental Protection Engineering. It is designed as an on-site preparation and disinfection equipment for various water treatment scenarios. This equipment adopts advanced electrolysis technology, using industrial salt and water as raw materials, and generates high-purity and highly stable sodium hypochlorite disinfectant through electrolysis reaction in real time, effectively solving the safety hazards and transportation and storage problems of traditional chlorine disinfection.
In terms of core performance, the equipment is equipped with an intelligent control system that supports fully automatic operation. It can automatically adjust the production amount according to the treated water volume, achieve precise dosing, and significantly reduce operating costs and manual maintenance intensity. The electrode plate is made of high-quality titanium based coating material, which has the characteristics of corrosion resistance, long service life, and high electrolysis efficiency, ensuring long-term stable operation of the equipment. The generated sodium hypochlorite solution has a wide spectrum of sterilization, with strong killing effects on bacteria, viruses, algae, and microbial spores, and no secondary pollution. The residual chlorine in the effluent is stable and meets the relevant hygiene standards for drinking water and sewage discharge in China.
This sodium hypochlorite generator is widely used in water treatment plants, sewage treatment plants, hospital sewage disinfection, swimming pool water treatment, circulating cooling water sterilization, as well as process water disinfection in food processing plants, slaughterhouses and other places. Its modular design makes installation easy, occupies a small area, and has strong adaptability, making it easy to connect to both new projects and old factory renovations. The overall structure of the equipment is compact, with complete safety protection measures and multiple safety mechanisms such as salt shortage alarm, over temperature protection, and overcurrent protection, ensuring the safety of operators and equipment. As an environmentally friendly disinfection solution, it not only enhances the automation level of water treatment processes, but also helps enterprises achieve green, safe, and efficient water quality management goals. It is an indispensable key equipment in modern water treatment engineering.
