800G QSFP-DD DR8 silicon optical module 1310nm 10km data center interconnection
Category:
electron/Optoelectronic device/Optical module
Model:
800G QSFP-DD DR8
Brand:
Ang Tong Technology
boxed type:
QSFP-DD
transmission rate:
800Gbps
transmission distance:
10km
Operating Wavelength:
1310nm
Fiber Type:
Single mode fiber (SMF)
Modulation format:
100G PAM4
number of channels:
8-way parallel
Application Scenarios:
Data Center 800GBASE-DR8
technical process:
Silicon photonics integration
Plug and unplug features:
Hot swappable
Retail Price
10,000,000.00USD
重量
kg
- Product Description
-
boxed type QSFP-DD
transmission rate 800Gbps
transmission distance 10km
Operating Wavelength 1310nm
Fiber Type Single mode fiber (SMF)
Modulation format 100G PAM4
number of channels 8-way parallel
Application Scenarios Data Center 800GBASE-DR8
technical process Silicon photonics integration
Plug and unplug features Hot swappable
Description :
The 800G QSFP-DD DR8 optical module is a high-performance, hot swappable optical transceiver device manufactured based on advanced silicon photonics integration technology. This product is designed to meet the growing bandwidth demands of modern data centers and is mainly used in 800GBASE-DR8 Ethernet link scenarios. By adopting 100G PAM4 modulation technology and an 8-channel single-mode parallel transmission architecture, the 800G QSFP-DD DR8 optical module can achieve high-speed data transmission while maintaining low power consumption, effectively supporting the core network interconnection requirements in high computing power application scenarios such as cloud computing, artificial intelligence training, and large-scale data storage.
In the selection and application, the 800G QSFP-DD DR8 optical module is suitable for inter rack and long-distance back-to-back connections in data centers, especially in scenarios where traditional 100m multimode fiber limitations need to be overcome. Compared with multi-mode solutions such as SR8, the DR8 specification has a slightly higher cost, but with the low loss characteristics of single-mode fiber, it can significantly extend the transmission span and reduce the investment in relay equipment. When purchasing, it is necessary to confirm whether the switch ports support QSFP-DD configuration and 800G rate protocol. At the same time, it should be noted that the supporting fiber jumpers should be single-mode LC or MPO interfaces to avoid excessive insertion loss caused by mismatched mode field diameters, which may affect the link budget.
The 800G QSFP-DD DR8++silicon optical module from Angtong Technology is a hot swappable optical transceiver module manufactured based on silicon photonics integration technology. It is designed for use in data center 800GBASE-DR8 Ethernet links, using 100G PAM4 and 8-channel single-mode parallel technology, supporting a maximum transmission distance of 10km.
Product Parameter Model Name: QSFP-DD DR8++-800G-10km Package Type: QSFP-DD Wavelength: 1310nm Interface: MPO16/APC Optical Port Fiber Type: Single mode Commercial Temperature: 0-70 ℃ Rate: 800Gbps Maximum Transmission Distance: 10km Laser Type: PIN Digital Diagnosis (DDM): YesAfterSalesService :
