Rubber multi head thickness gauge
Category:
Instrumentation/Measuring instrument/Thickness gauge
Model:
LP-10-C
Brand:
Shandu
measurement range:
（0-10）mm
graduation value:
0.01mm
Measurement indication error:
±0.02mm
Diameter of the upper measuring head:
Φ10mm、Φ5mm、Φ2mm、1mm*4mm
Retail Price
10,000,000.00USD
重量
kg
- Product Description
-
measurement range （0-10）mm
graduation value 0.01mm
Measurement indication error ±0.02mm
Diameter of the upper measuring head Φ10mm、Φ5mm、Φ2mm、1mm*4mm
Description :
1、 Product Introduction
This thickness gauge is mainly used to measure the thickness of cables, wires, soft insulation and sheath materials, as well as the thickness of vulcanized rubber and plastic products.
Main performance and technical parameters: • Measurement range: 0-10mm; • Division value: 0.01mm; • Measurement indication error: ± 0.02mm; • Pressure and required mass: 20Kpa (160g), 70Kpa (140g), 20Kpa (40Kg), 20Kpa (28Kg) (mass includes measuring rod, measuring head, heavy hammer, etc.); Diameter of the upper measuring head: Φ 10mm, Φ 5mm, Φ 2mm, 1mm * 4mm.
AfterSalesService :
质保1年Key words:
