YXH-R30 circular air conditioner temperature controller display screen dual temperature display fan gear LCD digital tube module
Category:
electron/Sensors, sensitive components/Temperature regulator
Model:
YXH-R30
Brand:
IONIC
Product model:
YXH-R30
display type:
Customized segment code LCD
external structure:
rotundity
display color:
Yellow background with black text/Black background with yellow text
Temperature scale support:
Celsius (° C)/Fahrenheit (° F)
function indication:
Cooling/Heating/Four speed Wind Speed
application field:
Central air conditioning/fan coil unit temperature controller
brand logo:
IONIC
Retail Price
9,000,000.00USD
重量
kg
- Product Description
-
Product model YXH-R30
display type Customized segment code LCD
external structure rotundity
display color Yellow background with black text/Black background with yellow text
Temperature scale support Celsius (° C)/Fahrenheit (° F)
function indication Cooling/Heating/Four speed Wind Speed
application field Central air conditioning/fan coil unit temperature controller
brand logo IONIC
Description :
This product is a circular customized segmented LCD display module (model: YXH-R30) designed specifically for central air conditioning, fan coil units, and HVAC systems. This display module adopts high contrast yellow segment code display technology, which has excellent visual effects on a black background, ensuring that users can read data clearly in different lighting environments.
The layout of the main functional areas is scientifically reasonable, with integrated cooling (snowflake icon) and heating (sun/human icon) mode indicators above, which intuitively reflect the current operating status of the air conditioning. The central core area is a large-sized dual row digital display area that supports synchronous or switchable display of Celsius (° C) and Fahrenheit (° F) dual temperature scales, meeting the usage habits of users in different regions. The digital strokes are thick and clear, and can be easily recognized from a distance. There are four wind speed adjustment indicator icons (fan blades) at the bottom, which can accurately correspond to low, medium, high, and automatic wind speed levels, and the operation feedback is clear at a glance. The "IONIC" brand logo is printed below the screen to enhance the overall texture of the product.
This module is widely used in office buildings, hotels, shopping malls, and home central air conditioning control panels. As the core window of human-computer interaction, it is not only responsible for real-time feedback of temperature values, but also undertakes the task of mode switching and air volume adjustment status indication. The product has excellent electrical stability and weather resistance, and is compatible with various mainstream temperature controller motherboard drive solutions. It is an ideal choice for HVAC equipment manufacturers to enhance the technology and practicality of control panels. Suitable for various embedded installation scenarios, compact structure, convenient wiring, and easy batch assembly and maintenance.
