Liquid level transmitter (pressure, liquid level)
Category:
Instrumentation/transmitter /Pressure transmitter
Model:
TS218-LT
Brand:
Hebei Tiantai Industrial Automation Co., Ltd
measurement range:
0~4KPa...1MPa
Working Voltage:
14.5V~36V DC
output signal:
4-20mA/HART communication protocol, Profibus PA communication protocol RS485
Accuracy:
± 0.075%, ± 0.1%, ± 0.2%, ± 0.5%, upper range limit
Display:
LCD、OLED
Pressure interface:
flange connection
Operating Temperature:
-40℃~ 80℃
Explosion-proof type:
Explosion proof type, intrinsic safety type
Retail Price
45,612,000.00USD
重量
kg
- Product Description
-
measurement range 0~4KPa...1MPa
Working Voltage 14.5V~36V DC
output signal 4-20mA/HART communication protocol, Profibus PA communication protocol RS485
Accuracy ± 0.075%, ± 0.1%, ± 0.2%, ± 0.5%, upper range limit
Display LCD、OLED
Pressure interface flange connection
Operating Temperature -40℃~ 80℃
Explosion-proof type Explosion proof type, intrinsic safety type
Description :
The TS218 series high-precision single flange intelligent transmitter is designed for high temperature, corrosive media, and harsh industrial environments, with dual certification of explosion-proof and intrinsic safety, meeting the safety requirements of flammable and explosive environments. Adopting a diaphragm structure and high-precision monocrystalline silicon sensor as the core, it is suitable for working conditions with high temperatures up to 300 ℃ (diaphragm high temperature resistance, electronic component working temperature -40 ℃~80 ℃). Combining digital AD acquisition technology and intelligent temperature compensation algorithm, providing high-precision signal output to ensure stability. Its intelligent circuit design includes anti-interference devices, multi-level protection circuits, and self diagnostic functions. And after strict semi-finished and finished product testing, aging screening, the performance is reliable, achieving high-precision measurement of ± 0.1% and long-term stability of ≤± 0.05% range limit/3 years. The product has a built-in multifunctional display screen that can display pressure values, percentages, and bivariate data in real time, and supports more than 20 operational functions such as range migration, zero and frequency adjustment, and data recovery. The explosion-proof shell design with IP67 protection level, combined with wide temperature adaptability, is suitable for complex industrial automation systems. Suitable for explosive hazardous areas such as petroleum, chemical, and metallurgical industries, especially for long-term monitoring of high-temperature and highly corrosive media.
Product application:
Petroleum, chemical, metallurgy, and electricity
• Power plants, pharmaceuticals • Machinery manufacturing
• Hydraulic and Pneumatic Control • Urban Natural Gas
