Level transmitter
Category:
Instrumentation/transmitter /level transmitter
Model:
TS300-B
Brand:
Hebei Tiantai Industrial Automation Co., Ltd
measurement range:
0~1mH2O...200mH2O
Working Voltage:
9~32V DC
output signal:
4~20mA, 4~20mA/HART communication protocol RS485 、0~10V 、0~5V
Accuracy:
± 0.2%, ± 0.5% upper range limit
Display:
LCD、LED
Pressure interface:
Threaded connection, chuck
Operating Temperature:
-40℃~ 80℃
Explosion-proof type:
Explosion proof type, intrinsic safety type
Retail Price
45,612,000.00USD
重量
kg
- Product Description
-
measurement range 0~1mH2O...200mH2O
Working Voltage 9~32V DC
output signal 4~20mA, 4~20mA/HART communication protocol RS485 、0~10V 、0~5V
Accuracy ± 0.2%, ± 0.5% upper range limit
Display LCD、LED
Pressure interface Threaded connection, chuck
Operating Temperature -40℃~ 80℃
Explosion-proof type Explosion proof type, intrinsic safety type
Description :
The TS300 series input type split type liquid level gauge adopts a split type design, which separates the high protection probe from the explosion-proof display module, balancing safety and flexibility in complex environments. The probe part has passed IP68 waterproof certification and can work in liquids for a long time, with a maximum measurement depth of 200 meters. It is suitable for deep water and high-pressure scenarios (such as reservoirs and offshore platforms); The display module has an IP67 protection level and intrinsic safety explosion-proof certification (Ex ia IIC T6 Ga), and can be installed in a safe location in hazardous areas to ensure data visualization and operational safety. The liquid level gauge adopts a fully stainless steel sealed structure and digital temperature compensation technology, combined with nonlinear correction algorithm, to achieve high-precision measurement of ± 0.2% F.S. The probe and display module are connected through waterproof cables, supporting RS485 (custom protocol) or HART communication protocol, seamlessly integrating with industrial control systems to meet automation integration requirements.
Product application:
Urban water supply and sewage treatment
Petroleum mining and reservoir testing
Chemical raw materials, hydrological ships
