Pressure transmitter 2
Category:
Instrumentation/transmitter /Pressure transmitter
Model:
TS200-H
Brand:
Hebei Tiantai Industrial Automation Co., Ltd
measurement range:
-100KPa…0～10KPa…100MPa
Working Voltage:
9~32V DC
output signal:
4~20mA, 4~20mA/HART communication protocol RS485 、0~10V 、0~5V
Accuracy:
± 0.2%, ± 0.5% upper range limit
Display:
LCD、LED
Pressure interface:
Threaded connection, chuck
Operating Temperature:
-40℃~ 80℃
Explosion-proof type:
Intrinsic safety type
Retail Price
45,612,000.00USD
重量
kg
- Product Description
-
measurement range -100KPa…0～10KPa…100MPa
Working Voltage 9~32V DC
output signal 4~20mA, 4~20mA/HART communication protocol RS485 、0~10V 、0~5V
Accuracy ± 0.2%, ± 0.5% upper range limit
Display LCD、LED
Pressure interface Threaded connection, chuck
Operating Temperature -40℃~ 80℃
Explosion-proof type Intrinsic safety type
Description :
The TS200-H pressure transmitter is a compact industrial measurement device based on the Husman universal connector, designed specifically for complex scenarios in multiple industries. Its core adopts piezoresistive sensors, combined with digital AD acquisition technology, to provide high-precision signal output. The product has been automatically tested by a computer, achieving zero point and performance compensation over a wide temperature range to ensure stability. Its intelligent circuit design includes anti-interference devices, multi-level protection circuits, and intrinsic safety circuits. After rigorous testing of semi-finished and finished products, as well as aging screening, the performance is reliable and the long-term stability is ≤ ± 0.15% FS/year, ensuring accurate and reliable data. Suitable for industrial sites such as hydrology and water resources, petroleum and petrochemicals, and electricity. The universal design of the Husman connector makes it easy to install, highly compatible, compact in size, and cost-effective, making it an economical and efficient industrial pressure monitoring solution.
Product application:
• Hydrology and water resources
• Petroleum and petrochemical industry
• Electricity
• Mechanical manufacturing
• Hydraulic and pneumatic control
